Laboratory Clean Bench
The LCB-2G is a high-performance horizontal laminar flow cabinet designed to provide a Grade 100 sterile workspace for two users. Featuring a SUS304 stainless steel workbench, HEPA filtration, and an intuitive LCD control interface, it ensures both precision and safety for a wide range of laboratory and industrial applications.
Product Details
The LCB-2G is a high-performance horizontal laminar flow cabinet designed to provide a Grade 100 sterile workspace for two users. Featuring a SUS304 stainless steel workbench, HEPA filtration, and an intuitive LCD control interface, it ensures both precision and safety for a wide range of laboratory and industrial applications.
Features
Horizontal Laminar Flow: Specifically designed with a horizontal air supply system to maintain a stable Level 100 (Federal 209E) sterile environment for sensitive operations.
Digital LCD Interface: Features a smart LCD control panel for precise monitoring and user-friendly management of airflow speed and system timing.
High-Quality SUS304 Worktop: The workbench is constructed from corrosion-resistant SUS304 brushed stainless steel, ensuring durability and easy decontamination.
Efficient HEPA Filtration: Equipped with a dual-stage system (Primary + HEPA) to effectively capture microscopic particles and extend the lifespan of the high-efficiency filter.
Safety UV Interlock: Integrated safety interlock between lighting and UV sterilization, including a programmable UV lamp timer for enhanced operator protection.
Ergonomic Sliding Door: Adopts an arbitrary positioning sliding door system, allowing flexible height adjustment for optimal ergonomics and airflow control.
Technical parameters
Air supply | Horizontal air supply |
NO.Index / Model | SW-CJ-2G |
Cleaning level | Grade 100 (209E U.S.Federal) |
Number of bacteria | ≤0.5 / petri dish.hour (Diameter 90mm petri dish) |
The average wind speed | 0.25-0.45m/s |
Noise | ≤62dB |
Power supply | AC, 220V/50Hz |
Half ventilation peak value | ≤5μm (X、Y、Z direction) |
Illumination | ≥300LX |
Max.power consumption | 800W |
Dimension of working area(W*D*H)(mm) | 1150*410*580 |
Overall dimension(W*D*H)(mm) | 1310*590*1600 |
Specification and number of fluorescent lamp or UV lamp of ultravioet lights | 12W / 30W |
Note | Non-standard size can also be customized |
