The LCB-1B Horizontal Laminar Flow Cabinet is designed to provide a clean, particle-free working environment for laboratory operations requiring product protection. By delivering a continuous stream of HEPA-filtered horizontal airflow across the work area, the cabinet effectively minimizes airborne contamination and ensures a stable clean workspace for sample preparation, media handling, electronics assembly, and other precision applications.

Its robust steel construction, user-friendly control system, and high-efficiency filtration technology make it an ideal choice for research laboratories, pharmaceutical facilities, hospitals, and quality control environments.

Key Features

1. Horizontal Laminar Airflow Protection

The cabinet generates a uniform horizontal airflow that passes through a high-efficiency HEPA filter, creating a clean working environment and protecting samples from airborne contaminants.

2. Durable Construction

The cabinet body is fabricated from cold-rolled steel with an electrostatic powder-coated finish for excellent durability and corrosion resistance. The work surface is made of SUS304 brushed stainless steel, providing easy cleaning and long-term reliability.

3. Adjustable Sliding Front Window

Equipped with an arbitrary-position sliding sash system, allowing users to adjust the opening height according to operational requirements while maintaining comfortable access to the workspace.

4. LCD Digital Control System

Features an intuitive digital LCD control interface for convenient operation and monitoring of cabinet functions.

5. UV Sterilization Safety Interlock

The lighting and UV sterilization systems are interlocked to enhance operational safety. The UV lamp timer function supports scheduled sterilization and helps maintain a clean working environment.

6. Optimized Airflow Design

The semi-enclosed work chamber design forms a protective airflow curtain that helps prevent external contaminants from entering the work area while maintaining workspace cleanliness.

7. Dual Filtration System

The cabinet incorporates both a pre-filter and a HEPA filter. The pre-filter captures larger particles, reducing the load on the HEPA filter and extending its service life.

8. Easy Mobility

Mounted on heavy-duty casters, allowing convenient positioning and relocation within laboratory facilities.

Applications

Cell culture preparation

Microbiology research

Pharmaceutical sample handling

Plant tissue culture

Media preparation

Precision electronics assembly

Optical component assembly

Quality control laboratories

Research and educational institutions

Technical Advantages

Uniform horizontal clean airflow

High-efficiency HEPA filtration

Low-noise operation

Corrosion-resistant stainless steel work surface

User-friendly digital control panel

UV sterilization function

Easy maintenance and cleaning

Reliable protection for sensitive samples

Typical Working Principle

Ambient air is first drawn through a pre-filter to remove larger particles. The air then passes through a high-efficiency HEPA filter, which removes airborne contaminants before delivering a continuous horizontal laminar airflow across the work area. This filtered airflow protects samples from environmental contamination and maintains a clean operating environment throughout the working chamber.
